Eric Evans on Repositories

Domain Driven Design by Eric Evans is the bible of that school of software development. It’s one of the most influential books in the realm of enterprise application architecture. Evans brings a real clarity of purpose to both the analysis and implementation of business software. I read it back in 2004 when it was first published and, along with Martin Fowler’s ‘Patterns of Enterprise Application Architecture’, has probably had the most influence on the way I think about building business systems. I’m not alone, you really have to read it if you want to be taken seriously as an application architect.

There’s been a bit of a backlash recently against a tendency in DDD circles to treat ‘the blue book’ almost too literally as a bible, but that shouldn’t detract from what is a fantastic piece of work.

The term ‘repository’ as a way of encapsulating  object persistence is well defined in the book and Evan’s definition is often referred to when discussing the repository pattern. I thought it was worth re-reading the chapter on Repositories and summarising it here so that I have a baseline for any further discussions.

Part II of the book describes a way of modelling user domains using object oriented programming. The technique is to describe your model in terms of entities and value types grouped together in aggregates.  In simple terms an aggregate is an object graph that has a lifecycle determined by the root entity. For example, an aggregate might have a root of customer with related orders, order-lines, address etc. An order does not have an existence separate from a customer. If the customer was deleted you would expect the rest of the graph; orders, order-lines etc; to be deleted as well. A product on the other hand, while it has a relationship with an order-line, also has a life cycle independent of that order-line.

Repositories are responsible for persisting entities and value types. They are described in their own section in chapter 6 and are said to have the following advantages:

• “They present clients with a simple model for obtaining persistent objects and managing their life cycle.”
• “The decouple application and domain design from persistence technology, multiple database strategies, or even multiple data sources.”
• “They communicate design decisions about object access.”
• “They allow easy substitution of a dummy implementation, for use in testing (typically using an in-memory collection)”

Thus the core purpose of the repository is to encapsulate persistence. The client should appear to be simply using an entity collection and all the details of object relational mapping and specific data access APIs should be hidden behind that collection like interface. Repositories should only be provided for aggregate roots:

“For each type of object that needs global access, create an object that can provide the illusion of an in-memory collection of all objects of that type. Set up access through a well-known global interface. Provide methods to add and remove objects, which will encapsulate the actual insertion of removal of data in the data store. Provide methods that select objects based on some criteria and return fully instantiated objects or collections of objects whose attribute values meet the criteria, thereby encapsulating the actual storage and query technology. Provide repositories only for aggregate roots that actually need direct access. Keep the client focused on the model, delegating all object storage and access to the Repositories.”

Transactions should not be a concern of the repository. He suggests that the client should handle them: “Leave transaction control to the client”. Interestingly, Evans does not mention the Unit of Work pattern in the repository discussion although it’s implied in the section on transactions.

Entity creation should not be the concern of the repository. Keep the concept of ‘factory’ and ‘repository’ distinct, although, in theory, a repository might use a factory internally.

In chapter 9, Evans describes ‘specifications’ as a way of encapsulating queries as part of the domain model. Much of the detail is concerned with providing a single interface for both in-memory (Java in his case) and repository level (SQL) querying. The core point is that specification definition is a domain concern and is best decoupled from the repository, although earlier he does say that in simple situations it might make sense to have methods on the repository to encapsulate queries.

There is also an excellent discussion of the compromises that may have to be made to co-ordinate the object and relational schemas.

So the core message is that repositories are a collection like interface that encapsulate persistence and that queries should encapsulated in the domain as specifications.

Re-reading the section on repositories and thinking about my own use of the term ‘repository’ in software I’ve been building recently tells me that I’m mostly in agreement with Evans. I think I’ve neglected to enforce the aggregate root rule, my repositories will persist any entity in my domain. In practice I don’t have well defined aggregates in my domain and that’s something I should improve. I’ve also allowed unit of work concerns to leak into my repositories. That’s something I’m keen to correct. As for the debate about exposing IQueryable’1, Evans doesn’t have much to say. Obviously, Java doesn’t have anything similar to LINQ so it wouldn’t be an option in any case, but the emphasis on treating the repository as a domain collection does fit quite nicely with the pattern of having specifications implemented as extension methods of a repository that implements IQueryable’1.
